TS-Optics NanoTracker – compact camera tracking mount for astrophotography


Τhe smallest astronomical tracking device for perfect astro photos



With TS NanoTracker you can take impressive pictures of the starry sky. All you need is a camera and a photo tripod. The NanoTracker ensures accurate tracking and is always there. The NanoTracker is not only intended for experienced astrophotographers who like to be on the go. It is also ideal for the entry into astrophotography, thanks to its simple operation.

By the rotation of the earth around its own axis, all celestial objects seem to move from east to west. The NanoTracker compensates for this movement. This way, the stars are not distorted into dashes. The impression remains natural. For an exact alignment on the northern hemisphere, the polar direction finder is at your disposal. Simply align it with the Pole Star and the NanoTracker will be in the right position.

With a compass and your smartphone´s tilt sensor, you can also set up the NanoTracker well, both in the northern and southern hemispheres.

Tracking speeds: 1x, 0.5x, lunar, solar and max. 50x star speed
Area of application: worldwide – northern/southern hemisphere switchable
Motor: Stepper motor
Mechanics: Steel-brass worm wheel drive 50 teeth
Bearing: 2 ball bearings
Connection tripod side: 1/4″ female thread
Connection camera side: 1/4″ male thread
Load capacity: 2 kg
Power supply: 3x AA batteries (LR6) or Mini USB
Dimensions: Tracker 60x98x44 mm, hand controller 50x105x22 mm (without cable)
Weight: Tracker 350 grams, hand controller 80 grams

Additional information

Weight 10 kg

Computerised / GoTo, Equatorial


Astrophotography, Deep Sky
